EUM6862.pdf• Built in 24V Full-wave Motor Driver for Fan Motor
• Built in Kickback Voltage Protection, No Zener
Diode Need
• External Programmable Soft Start and Soft
Restart Function
• Wide Input Range 3V~28V
• PWM Fan Speed Control
• Programmable Minimum Fan Speed
• Built in Soft Switching Function
• Built in Hall Bias
• Lock Protection and Auto Restart
• Fan Rotation Speed Feedback FG Output
(EUM6862/B)
• Fan Rotation Detection RD Output
(EUM6862/A)
• Thermal Shutdown Protection
• Available in TSSOP-16 and TDFN-14 Packages
• RoHS Compliant and 100% Lead (Pb)-Free
Halogen-Free
• Single-phase full-wave driver.(1A,16V)
• Variable speed control with thermistor input or
PWM drive with additional components.
• Minimum speed setting pin.
• Over-Current protection.
• Lock-Protection and Auto-Recovery.
• Hall bias built-in.
• Thermal shutdown function.
