SGM2208.pdf• Power Input Voltage Range (Relative to OUT): 0V to 24V
• Bias Supply Voltage Range (Relative to OUT): 2.7V to 25V
• Single Resistor Programs Output Voltage
• SET Pin Current: 50μA (TYP)
• Output Adjustable to 0V
• Low Output Noise: 32μVRMS (10Hz to 100kHz)
• Low Dropout Voltage: 155mV (TYP) at 3A
• Current Limit with Foldback
• Over-Temperature Protection
• Outputs May be Paralleled for Higher Current and Heat Spreading
• -40℃ to +125℃ Operating Temperature Range
• Output Current: 3A
• Single Resistor Programs Output Voltage
• 50μA Set Pin Current: 1% Initial Accuracy
• Output Adjustable to 0V
• Low Output Noise: 40μVRMS (10Hz to 100kHz)
• Wide Input Voltage Range: 1.2V to 23V
(DD-Pak and TO-220 Packages)
• Low Dropout Voltage: 310mV
• <1mV Load Regulation
• <0.001%/V Line Regulation
• Minimum Load Current: 1mA
• Stable with Minimum 10μF Ceramic Capacitor
