• Wide Input Range: 3V-40V

• With up to 45V Transient Input Voltage

• Maximum Output Current : 300mA

• Output Voltage:

  - 3.3V and 5V (Fixed Output)

  - 1.2V, 1.8V, 2.5V, 3V, 4.2V and 4.5V

    (Need contact SCT sales)

• Output Voltage Accuracy:

  - T=25℃ : ±1%

  - T= -40℃~ 125℃ : ±2%

• Low Quiescent Current : 2.4uA

• Low Dropout Voltage ：

  - 230mV at 100mA load current

  - 470mV at 200mA load current

• Support Output Capacitors Range:

  - 3.3uF~220uF

  - Low-ESR : 0.001Ω~ 5 Ω

• 550us Internal Soft-start Time

• Integrated Short-Circuit Protection with OCFB

  (Over Current Fold-back) Feature

• Precision Enable Threshold for Programmable

  Input Voltage Under-Voltage Lock Out Protection

  (UVLO) Threshold and Hysteresis

• Power-Good Feature is available

• Over-Temperature Protection

• Available Package:

  TSOT23-5 / TDFN2x2-6 / eMSOP3x3-8
